60° GLOSS METER / ISO 17025 AMECaL
£1,625.00
SG060 gloss meter features with 60° angle, manufactured according to
ISO2813 and GB/T 9754. It is also compatible with the standards of ASTM
D523, ASTM D2457. NHG60 conforms to JJG696 first class gloss meter
working requirement, corresponding with CIE 1931(2°) under CIE C light
source.
NHG60 gloss meter can test material with gloss (0-1000Gu), and universally
apply to paint, ink, stoving varnish, coating, wood products; marble, granite,
vitrified polished tile, pottery brick and porcelain; plastic, paper; hardware
industries, etc. for gloss measurement and gloss data transmission.
Specifications:
SG060 60° Precise Gloss Meter
Model SG060
Measure Angle 60°
Comply with standard ISO 2813、GB/T 9754、ASTM D
523、ASTM D 2457
Measuring Area (mm) 9X15
Measurement Range 0~1000GU
Division Value 0.1GU
MeasurementRange 0-10GU 10-100GU 100-1000GU
Repeatability ± 0.1GU ± 0.2GU ± 0.2%GU
Reproducibility ± 0.2GU ± 0.5GU ± 0.5%GU
Measurement Standard Conform with JJG696 first class gloss meter working
requirement
Chromaticity Corresponding Corresponding with CIE 1931(2°) under CIE C lightsource
Errors ±1.2 , ± 1.2%
Measuring Time 0.5s
Dimension L*W*H : 160mm*75mm*90mm
Weight 350g
Language Chinese/English
Battery 3200mAh Li-ion Battery, >10000 times(within 8 hours)
Viewing Screen TFT 3.5 inch, capacitive touch screen
Interface USB/RS-232
Data Save Basic mode:1000, Statistical Mode: 5000, Continuous
mode : 5000
Software GQC6 Quality Control Software with QC report printing
functions and more extended functions.
Operation Temperature 0~40℃（32~104°F）
Storage Temperature -20~50℃（-4~122°F）
Humidity <85% relative humidity, no condensation
Standard Accessories Power Adapter, USB cable, User Manual, CD (Including
QC software), Calibration Plate
Optional Accessories Miniature Printer
Note The specifications are subject to change without notice
Quantity
Features
1. 60° angle for semi gloss
2. Display 5 sets of measurement data, good for comparison
3. Measuring mode: basic measurement, statistical measurement, continuous measurement, QC measurement (only for GQC6 software).
4. Continuous mode to check uniformity over large areas
5. Connect to PC, more extend functions
6. Input gloss value manually
7. Large touch screen operation, easy to use
8. Beauty appearance, good man-machine communication interface
9. Powerful functions to meet many different requirements
10. Large storage to save over 5000 data
11. Built-in lithium ion rechargeable battery.
Specifications
Model SG060
Measure Angle 60°
Comply with standard ISO 2813、GB/T 9754、ASTM D
523、ASTM D 2457
Measuring Area (mm) 9X15
Measurement Range 0~1000GU
Division Value 0.1GU
MeasurementRange 0-10GU 10-100GU 100-1000GU
Repeatability ± 0.1GU ± 0.2GU ± 0.2%GU
Reproducibility ± 0.2GU ± 0.5GU ± 0.5%GU
Measurement Standard Conform with JJG696 first class gloss meter working requirement
Chromaticity Corresponding Corresponding with CIE 1931(2°) under CIE C lightsource
Errors ±1.2 , ± 1.2%
Measuring Time 0.5s
Dimension L*W*H : 160mm*75mm*90mm
Weight 350g
Language Chinese/English
Battery 3200mAh Li-ion Battery, >10000 times(within 8 hours)
Viewing Screen TFT 3.5 inch, capacitive touch screen
Interface USB/RS-232
Data Save Basic mode:1000, Statistical Mode: 5000, Continuous mode : 5000
Software GQC6 Quality Control Software with QC report printing functions and more extended functions.
Operation Temperature 0~40℃（32~104°F）
Storage Temperature -20~50℃（-4~122°F）
Humidity <85% relative humidity, no condensation
Standard Accessories Power Adapter, USB cable, User Manual, CD (Including
QC software), Calibration Plate
Optional Accessories Miniature Printer
Note The specifications are subject to change without notice
